Eaton UPS 5SC 1000i 1000VA (5SC1000I)

~~$ 290.00~~ $ 280.00

Part Number: 5SC1000I
Rating (VA / W): 1000VA/700W
Form factor: Tower
Input voltage range: 184-276 V
Frequency: 50 / 60 Hz
Output voltage: 230V
Outputs: (8) C13
Warranty: 2 Years on Part.

Order Now

Specification

Part Number: 5SC1000I
General specifications:
Product Name: Eaton 5SC 1000i
Rating (VA / W): 2000VA/1200W
Form factor: Tower
Product Length/Depth: 150 mm
Product Height: 210 mm
Product Width: 340 mm
Product Weight: 11.1 kg
Battery
Battery type: Lead-acid maintenance-free (replaceable)
Runtime graph: View runtime graph
Battery replacement: User replaceable
Battery quantity: 2
Battery management: ABM or constant voltage charging method (user selectable), automatic battery test, deep discharge protection
Battery rating: 12 V / 9 Ah
Extended battery capability: No
Electrical output
Receptacle: (8) C13
Voltage: 230V
Wattage: 700 W
Output power factor: 0.7
Output voltage range: 230 V (+6%/-10%)
Output waveform: Sine wave
Output nominal voltage: 230V default (220/230/240V)
Feed type: 1
Topology: Line-interactive
VA rating: 1000 VA
Electrical input
Input connection: C14
Input nominal voltage: 230V default (220/230/240V)
Nominal frequency: 50-60 Hz
Input voltage range: 184-276 V
Input frequency range: 45-55 Hz (50 Hz system), 55-65 Hz (60 Hz system)
Communications
Includes network card: No
Communication: USB port (HID compliant), Serial port (RS232)
Ethernet interface: No
User interface: LCD Display
Potential free switch contact: No
Expansion slots: No
Software compatibility: Eaton Intelligent Power Protector
Type of interface: Other
Environmental
Altitude: 2000 m
Noise level: <40 dB at 1 meter
Temperature range: 0-90% non-condensing
Relative humidity: 0-90% non-condensing
Additional specifications
Construction type: Free standing model
Enclosure: Black
Package contents:
-USB cable
-Serial cable
-(2) IEC-IEC cables
-Quickstart guide
-Safety instructions
Phase (output): 1
Auto shutdown function: Yes
Color: Black
Efficiency: 96
Rack mounting kit: No
Phase (input): 1
Warranty: 2 Years on Part
