Cisco CBS110-16T-EU Unmanaged 16-Port Gigabit Switch

~~$ 244.00~~ $ 235.00

Part Number: CBS110-16T-EU
Brand Name: Cisco
16 ports, 10/100/1000 Mbps
Ports : 16 x RJ45
Limited Lifetime Warranty

Order Now

Specification

Part Number: CBS110-16T-EU
Device type
Gigabit switch, 16 ports, 10/100/1000 Mbps, RJ-45, rack mount type, suitable for connection. Very high speed network system
Format & Standards
Format : Rack mount
Network Management Type : Unmanaged
Performance
Capacity in millions of packets per second (mpps) (64-byte packets) : 23.8 mpps
Switching capacity in gigabits per second (Gbps) : 32 Gbps
Ports & Interface
Primary Ports : 16 x RJ45
Primary Port Speed : 10/100/1000Mbps
Data Transmission
Head-of-line (HOL) blocking HOL blocking prevention
MAC Address Table : 8K
Jumbo Frames : 9216 bytes
Quality of Service (QoS) : 802.1p priority based, 4 hardware queues, priority queuing and Weighted Round-Robin (WRR)
Loop detection : Helps discover loops in the network to avoid broadcast storms
Cable diagnostics : Quickly identify and troubleshoot network cable faults and/or shorts
Media-dependent interface : Automatic Media Dependent Interface (MDI) and MDI crossover (MDI-X)
Standards : IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet, 802.3af, Power over Ethernet
Operation Systems
Flash : 16 MB for CBS110-16T, CBS110-16PP
CPU : 400 MHz ARM for CBS110-16T
CPU memory : 128 MB for CBS110-16T, CBS110-16PP
Power
110-240VAC, 50-60 Hz, internal, universal
Details
Buffer Memory : 2 Mbit
LED : Power, link/activity (cable diagnostics, loop detection), Gigabit, * PoE, * Max PoE,. *if present
Power : 110V=11.33W , 220V=11.53W
Dimensions & Weight
Dimensions : 279 x 170 x 44 mm (11 x 6.7 x 1.73 in)
Weight : 0.97 kg (2.14 lb)
Environmental
Temperature : Operating temperature: 32° to 104°F (0° to 40°C)Storage temperature: -4° to 158°F (-20° to 70°C)
Humidity : Operating humidity: 10% to 90%, relative, noncondensingStorage humidity: 5% to 90%, relative, noncondensing
Packaging
Package Contents : Cisco Business 110 Series switchPower cord or adapterQuick start guideMounting kit
Warranty: Life time warranty.
