Hikvision DS-3WR12C AC1200 Wireless Router
$ 32.00
$ 27.00
Part Number: DS-3WR12C
AC1200 Wireless Router
Four 5-dBi amplified antennas
Beamforming optimizes signal
Dual band – Smart signal switching
Broadband account synchronization
Warranty: 1 Year on Part.
Order Now
Specification
Part Number: DS-3WR12C
General
Product Dimension (W × H × D): 248.40 mm × 154.80 mm × 213.34 mm (9.78"× 6.09"× 8.40")
Package Dimension (W × H × D): 306 mm × 290 mm × 59 mm (12.05"× 11.42"× 2.32")
Net Weight: 0.222 kg (0.489 lb)
Packing List: Wireless Router x 1, Ethernet cable × 1, Quick installation guide × 1
Packing Method: Single pack
Working Temperature: 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
Working Humidity: 10% to 90% RH non-condensing
Storage Temperature: -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
Storage Humidity: 5% to 90% RH non-condensing
Installation Mode: Desktop installation
Max. Power Consumption: ≤ 9 W
Gross Weight: 0.722 kg (1.592 lb)
Wireless Parameter
Data Rate:
≤ 1167 Mbps
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps
Wireless Standard: IEEE 802.11/a/n/ac wave 2 @5GHz, IEEE 802.11b/g/n @2.4GHz
Working Frequency Band: 2.4 GHz，5 GHz
Transmitting Power
CE:
<20 dBm(2.4G)
<23 dBm(5G)
Wireless Performance
-4 × 4 MU-MIMO supported
-Beamforming supported
Receiving Sensitivity
-58 ± 2 dB@AC80 -MCS9
-84 ± 2 dB@AC80 -MCS0
Antenna: 4 high gain antennas
Operating Frequency:
2.4 GHz: US/2412-2472 MHz(CH1-CH13)
5 GHz: US/5180-5240 MHz(CH36-CH48)
5 GHz: US/5740-5805 MHz(CH149-CH161)
EIRP Power(Max.):
2.4 GHz: 19.86 dBm
5 GHz: 22.96 dBm
Hardware Parameter
Network Interface: 1*10/100Mbps WAN port 3*10/100Mbps LAN ports
LED Indicator: LED indicator
Reset: Reset button
Power Supply Method: 9 VDC, 1 A power adapter power supply
Power Specifications: 9 VDC, 1 A
Software Function
Application function:
Wireless Router Mode, Wireless Repeater Mode, Client + AP, WISP, and AP Mode supported
DHCP Server supported
Guest Network Configuration supported
Signal Adjustment supported
WiFi Schedule supported
Security Mode: WPA-PSK, WPA2-PSK, WPA and WPA2 supported
Security Mechanism: Hide SSID
Management Method: Web
Upgrade: Web Update and Upgrade
System Log: System log
Warranty: 1 Year on Part.
