Hikvision Camera DS-2CE16U1T-ITPF

~~$ 60.00~~ $ 55.00

Specification

Part Number: DS-2CE16U1T-ITPF
Camera
Image Sensor: 8.29 megapixel progressive scan CMOS
Max. Resolution: 3840 (H) × 2160 (V)
Min. Illumination: Color: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time: PAL: 1/12.5 s to 1/50,000 s, NTSC: 1/15 s to 1/50,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360°
Signal System: PAL/NTSC
Lens
Lens Type: 2.8 mm, 3.6 mm, 6 mm fixed lens
Focal Length & FOV: 102.2° (2.8 mm), 79° (3.6 mm), 50.8° (6 mm)
Lens Mount: M16
Image Settings: Brightness, Sharpness, DNR, Smart IR, HLC
Frame Rate
TVI: 8MP@12.5fps, 8MP@15fps, 4MP@25fps, 4MP@30fps,2MP@25fps, 2MP@30fps
CVI: 8MP@12.5fps, 8MP@15fps
AHD: 8M@12.5fps, 8M@15fps
CVBS: 960H P/N
Day/Night Mode: Auto/Color/BW (Black and White)
Wide Dynamic Range (WDR): Digital WDR/ 105 dB
Image Enhancement: BLC
White Balance: Auto/Manual
AGC: Yes
Interface
Video Output: 1 HD analog output，TVI/AHD/CVI/CVBS
General
Material: Plastic
Dimension: 58 mm × 61 mm × 159.8 mm (2.28" × 2.40" × 6.42")
Weight: Approx. 210 g (0.46 lb.)
Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Communication: Up the coax, Protocol: HIKVISION-C (TVI output)
Language: English
Power Supply: 12 VDC ±25%
*You are recommended to use one power adapter to supply the power for one camera.
Consumption: Max. 5.3 W
IR Range: Up to 30 m
Approval
Protection: IP67
Warranty: 1 Year on part.
